The Wall Mount Power Failure Alarm alarms with loud buzzer and flashing LED.

POWER FAIL ALARM MODEL PFA-5
The best power failure alarm
  • Always on duty – ultra-low power consumption allows Lithium battery to last for 10 years or more.

  • Low Battery alarmIf the battery runs low, the Power Fail Alarm beeps and flashes to let you know.
  • Very loud alarm. 103dB! warbling pattern cuts through ambient noise.
  • Silence button with  30-minute “snooze alarm” setting.
  • Bright flashing beacon LED. Bright enough to be visible in daylight.
  • Weatherproof box.

The wall mounted power fail alarms continuously monitor AC power outlets and if there is a power interruption, the LED flashes and a 103dB buzzer sounds.  The buzzer can be silenced with the front button.

Simple installation, just snap in the long-life lithium battery included.  After that you are protected for the next 10 years.

OPERATION

The front button is illuminated when plugged into power. When the power fails, pressing the front button silences the buzzer.  A selectable “snooze alarm” feature will cause the alarm to come back every 30 minutes until power is restored. Will alarm for 50 hours straight with the supplied Lithium battery.

Flexible logic so it can detect millisecond blips, (useful for computer equipment) or only report power outages longer than 10 seconds, or longer than 30 seconds. Latching or non-latching alarm. (resets automatically when power is resotred, or at your option, it must be reset) Also, an mode for a 15-minute delay for either the audible alarm or auxiliary output.  Different modes are set with jumpers on the circuit board.


POWER ALARM PFA-6 WITH EURO PLUG
FEATURES

Very loud beeping audio buzzer – 103dB at 2 ft will never be missed even in noisy factories.

Extremely low power consumption allows the lithium battery (included) to last up to 10 years.  If battery power is low due to excessive alarming time, a low-battery warning alarm sounds for many weeks.
more about battery power

Relay output available provides a contact close or open to trigger an autodialer, building alarm system, or other remote device.  Relay output is maintained for the duration of the power failure.

Weatherproof box is rated IP65.

MODELS AVAILABLE

PFA-5 (120VAC operation) comes with the common NEMA 5-15 plug connected with 10 foot rubber cord (type SJOOW )

PFA-6 is suitable for voltages from 208-277VAC and comes with choice of plug. (NEMA 6-15, Euro, UK, Australia/NZ)  Cord length  is 2-3 m) depending on availability.

PLUG TYPES AVAILABLE
NEMA 5-15 plug
NEMA 5-15
NEMA 6-15
EURO
UK
  • Power consumption (when not alarming)…………………11µA
  • Power consumption (during alarm)………………………..55µA
  • Voltage input range………………………………………….85-277VAC
  • Buzzer volume………………………………………………..103dB at 2 ft
  • Buzzer materials………………………………………………316SS, PPE
  • Operating temperature……………………………………….-40 to 65ºC
  • Enclosure dimensions………………………………………..4x4x2 inches
  • Enclosure ingress protection……………………………….IP65  (NEMA 4X)
  • Beacon lens material…………………………………………Lexan

PFA-5                 North American 120V plug (NEMA 5-15)
PFA-6                 North American 240V plug (NEMA 6-15)
PFA-6-UK           UK plug
PFA-6-EU           Euro plug
PFA-6-AU
Australian plug

Order Here

PFA-5 (120VAC)

$155. Price includes Lithium battery

PFA-6 (208-250VAC)

$175. Price includes Lithium battery

Plug type

Options

Relay output cable

Specify the length needed to connect to building alarm system. Heavy 0.032″ jacket for superior durability, Eight stranded conductors x 24 gage.
[C-8] $0.58/ft
